Rechargeable LED Display Front Service Tool

Rechargeable LED Display Front Service Tool – Overview

The Rechargeable LED Display Front Service Tool is a high-performance, portable solution designed for efficient front-access maintenance and replacement of small-pitch LED display modules. With multiple suction cup sizes and advanced safety features, it ensures precision handling and secure operation across a wide range of LED display models.

🔧 Product Specifications:

• Dimensions: 175 x 139 x 216 mm

• Suction Cup Sizes:

1. 135 x 213 mm

2. 135 x 150 mm

3. 135 x 90 mm

• Application: Ideal for small-pitch LED modules

⚡ HX02 II Technical Parameters:

• Charger Input Voltage: 100–240V AC

• Charger Output Voltage: 26V 0.8A

• Input Frequency: 50Hz / 60Hz (Standard 220V)

• Continuous Operation Time: Up to 20 minutes

• Standby Power Consumption: < 10μA

• Operating Temperature: -20°C to +45°C

• Relative Humidity Range: 15%–85% RH

• Power Rating: 300W

✅ Key Product Advantages:

• Compact & Lightweight Design: Easy to carry and handle in tight spaces.

• Ergonomic Structure: Enhances comfort and efficiency during long-term use.

• Multi-Size Vacuum Valve: Compatible with various module types and sizes.

• Optimized Air Duct System: Improves heat dissipation and extends motor lifespan.

• PCB Protection Limit Design: Prevents warping and damage to LED panels.

• Anti-static Technology: Safeguards sensitive LED components during installation.

• Backpack-style Carrying System: Ensures safe and convenient operation at height.

• Supports Charging While Using: Eliminates downtime during urgent repairs.

• Universal Compatibility: Works seamlessly with all series of LED display modules.
