5.0 Inch AMOLED Display Module 720x1280 Touch & MIPI Interface

Name: 5.0 Inch AMOLED Display Module 720x1280 Touch & MIPI Interface
Brand: REISSOPTO
SKU: P2.5-Indoor
Availability: InStock

5.0-Inch HD AMOLED Module with Touch Panel

Resolution: 720 × 1280 (HD)
Display Mode: AMOLED (Transmissive)
Interface: MIPI
Color Gamut: 110% NTSC
Driver IC: RM67295 | Touch IC: CST3640

Shenzhen Brownopto Technology presents the BR0500S001AMT001, a premium 5.0-inch AMOLED display module designed for high-end electronic applications. Combining a high-definition resolution with an ultra-wide color gamut and integrated capacitive touch capabilities, this module delivers an immersive visual experience for smart handheld devices and industrial HMI systems.

Get a quote Set OEM

CUSTOM OLED DISPLAY Details

Why Choose Our 5.0" AMOLED Display?

Unlike standard LCD screens, this AMOLED (Active Matrix Organic Light Emitting Diode) module utilizes self-emissive technology. This results in a thinner profile, lower power consumption for dark content, and significantly richer colors.

Stunning Visuals with 110% NTSC Color Gamut

110% NTSC Wide Color Gamut for Lifelike Imagery

Experience true-to-life colors. With a color gamut of 110% NTSC and a contrast ratio of 20,000:1, this display produces deep blacks and vibrant, saturated colors (16.7M), making it perfect for devices requiring high-quality image rendering.

Stunning Visuals with 110% NTSC Color Gamut

High Definition Clarity (296 PPI)

296 PPI HD Clarity on a 5-inch Display

The 720x1280 resolution on a 5-inch active area results in a pixel density of 296 PPI. This ensures sharp text, smooth curves, and detailed graphics, essential for user interfaces in medical or industrial equipment.

Integrated Capacitive Touch Panel

Integrated Capacitive Touch with CST3640 Controller

This module comes pre-assembled with a high-sensitivity capacitive touch panel driven by the CST3640 IC. The fully integrated solution simplifies your supply chain and assembly process, reducing development time.

Ultra-Thin & Lightweight Design

Ultra-Slim 0.84mm AMOLED Module

Leveraging AMOLED technology, the display module achieves an incredibly slim profile of just 0.84mm (excluding the touch panel assembly thickness). This allows for sleek, modern device designs without compromising on performance.

High-Speed MIPI Interface

High-Speed MIPI Interface Powered by RM67295

Equipped with a MIPI interface, the module ensures high-speed data transmission required for HD video and fluid UI animations, supported by the robust RM67295 driver IC.

Why Choose ReissOpto for Your OLED Projects?

Expert Engineering
ReissOpto leverages years of experience in LTPS AMOLED manufacturing. Our modules are designed to meet strict industrial standards, ensuring stable performance and high yield rates.

Comprehensive Quality Assurance
We implement rigorous testing protocols, including high/low-temperature storage (-40℃ to +80℃), thermal shock cycling, and ESD testing. Our visual inspection standards ensure that every OLED Display shipped meets Class A quality levels.

Flexible Customization
We understand that every project is unique. ReissOpto offers customization for FPC shape, interface definition, and cover lens design to perfectly integrate with your device's mechanical housing.

Technical Specifications

Manufactured to strict quality standards, the BR0500S001AMT001 is built for reliability and performance.

Product No: BR0500S001AMT001
Display Size: 5.0 inch (Diagonal)
Panel Type: AMOLED
Resolution: 720 (RGB) × 1280
Module Dimensions: 64.12(H) × 116.72(V) × 0.84(T) mm
Touch Panel Outline: 69.12(H) × 121.72(V) × 1.1(T) mm
Active Area: 61.88(H) × 110.02(V) mm
Driver IC: RM67295
Touch IC: CST3640
Interface: MIPI
Brightness (Surface): 700 cd/m²
Contrast Ratio: 20,000:1
Viewing Direction: All (Full Viewing Angle)
Operating Temperature: -20°C ～ 70°C
Storage Temperature: -30°C ～ 80°C

Application Scenarios

Handheld Terminals & POS
The integrated touch panel and high resolution make it an excellent choice for handheld payment devices, inventory scanners, and logistics terminals.

Smart Home Control Panels
Upgrade smart thermostats and home automation controllers with a display that offers wide viewing angles and premium aesthetics.

Medical & Industrial Instruments
Reliable operation in temperatures ranging from -20°C to 70°C ensures this display performs> Detailing the Copy Structure

I'm now drafting the product page content, following the plan developed earlier. I'm prioritizing the features, technical specs, and applications sections. I'm leaning heavily on Section 2 for the core features, to ensure accuracy and to provide the most marketable details. The biggest challenge is still the conflicting brightness specifications, but I've addressed this with the surface luminance clarification.

in demanding industrial and medical environments.

Reliability & Quality Assurance

Brownopto ensures every module undergoes rigorous testing before shipment, including:

High/Low Temperature Operation: Tested for 96 hours at -20°C and +70°C.
Thermal Shock: Tested for 10 cycles between -20°C and +70°C.
ESD Testing: Contact ±2KV, Air ±6KV to ensure static resistance.

Frequently Asked Questions (FAQ)

Q1: Does this module include the Touch Panel (TP)?
A1: Yes, this is a complete assembly including the AMOLED display and a capacitive touch panel driven by the CST3640 IC.

Q2: What is the interface type for this display?
A2: The display utilizes a MIPI interface for video data, which is standard for high-resolution mobile-style displays.

Q3: What is the viewing angle performance?
A3: As an AMOLED display, it features a "Full Viewing Angle" (All Direction), ensuring the image remains clear and color-accurate from any side.

Q4: Can I customize the FPC or Cover Glass?
A4: Yes, Brownopto offers OEM/ODM services. We can customize the FPC shape, interface definition, and the cover glass (including AF/AG coatings) to fit your specific housing.

Contact Us for a Datasheet & Sample
